Automation drawing tools in Logic Pro for iPad
Sometimes it is easier and more musical to write automation in real time by performing movements of onscreen controls while the project is playing. However, drawing automation can be faster and more precise. You draw the automation curve using touchscreen gestures with your finger or Apple Pencil. It also lets you easily experiment with movements that are difficult to perform in real time.
Creating or editing automation graphically requires the following steps:
Switch to Automation view. See Show automation.
Choose the parameter you want to automate. See Automation parameters.
Select the drawing mode. See Adjust automation.
Start drawing on the screen with various gestures using your fingers or Apple Pencil. See Add automation points.
Drawing tools
Similar to selecting a drawing tool, in Logic Pro, you tap a function button to select an edit mode that determines what happens when you tap or drag on the screen.
Move button: With the Move button
selected, you can move individual automation points or the automation curve (sections or the entire curve).Pencil button: With the Pencil button
selected, you can add, move, and delete individual automation points.Brush button: With the Brush button
selected, you can draw an automation curve (a series of automation points) or delete automation points.Curve button: With the Curve button
selected, you can bend the straight lines between automation points.
Modifier
These three modifier buttons provide additional control over automation edits:
Select button: With the Select button
(located to the left of the four function buttons) selected, you can select multiple automation points.Copy button: Available only when the Move button is selected, the Copy button
changes the move gesture to a copy gesture.Stepped Automation button: Available only when the Pencil, Brush, or Curve button is selected, the Stepped Automation button
acts as a modifier. Creating new automation points with the Pencil tool or Brush tool results in horizontal lines between automation points instead of lines that gradually change values between points.
